64CH-NVR
SRK-NVR-7108
5MP H265+ Encoding Two high-speed USB2.0 interfaces Upto 6TB SATA Interface HDD*2 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support ONVIF Protocol H.265+ Supported
| Main Processor | HISILICON |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Control Mode | USB mouse, Keyboard, Network |
| Performance | 5MP |
| VGA / HDMI | VGA / HDMI |
| Video | 8CH Resolution |
| Audio | 8CH Network Audio Input |
| Alarm | No |
| PlayBack | 4CH Playback |
| Digital Zoom | Yes |
| Protocol | Support ONVIF Protocol |
| Frame Rate Display | 1080P(1920×1080)25s/960P (1280×960) / 720P(1280×720)25s |
| PTZ | Supported |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 6TB, SATA Interface HDD*1 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK |
| Power Supply | 12V / 3A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-NVR-7110U
5MP H265+ Encoding Two high-speed USB2.0 interfaces Upto 6TB SATA Interface HDD*1 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support ONVIF Protocol H.265+ Supported
| Main Processor | HISILICON |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Control Mode | USB mouse, Keyboard, Network |
| Performance | 5MP |
| VGA / HDMI | VGA / HDMI |
| Video | 10CH Resolution |
| Audio | 10CH Network Audio Input |
| Alarm | No |
| PlayBack | 4CH Playback |
| Digital Zoom | Yes |
| Protocol | Support ONVIF Protocol |
| Frame Rate Display | 1080P(1920×1080)25s/960P (1280×960) / 720P(1280×720)25s |
| PTZ | Supported |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 6TB, SATA Interface HDD*1 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK |
| Power Supply | 12V / 5A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-NVR-7116
5MP H265+ Encoding Two high-speed USB2.0 interfaces Upto 6TB SATA Interface HDD*1 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support ONVIF Protocol H.265+ Supported
| Main Processor | HISILICON 3520D |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Control Mode | USB mouse, Keyboard, Network |
| Performance | 5MP |
| VGA / HDMI | VGA / HDMI : 1080(P) |
| Video | 16CH Resolution |
| Audio | 16CH Network Audio Input |
| Alarm | No |
| PlayBack | 4CH Playback |
| Digital Zoom | Yes |
| Protocol | Support ONVIF Protocol |
| Frame Rate Display | 1080P(1920×1080)25fps/960P/ (1280×960)/720P(1280×720)25fps |
| PTZ | Supported |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 6TB, SATA Interface HDD*1 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK |
| Power Supply | 12V / 3A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-NVR-7116U
5MP H265+ Encoding Two high-speed USB2.0 interfaces Upto 6TB SATA Interface HDD*1 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support ONVIF Protocol H.265+ Supported
| Main Processor | HISILICON 3520D |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Control Mode | USB mouse, Keyboard, Network |
| Performance | 5MP |
| VGA / HDMI | VGA / HDMI : 1080(P) |
| Video | 16CH Resolution |
| Audio | 16CH Network Audio Input |
| Alarm | No |
| PlayBack | 4CH Playback |
| Digital Zoom | Yes |
| Protocol | Support ONVIF Protocol |
| Frame Rate Display | 1080P(1920×1080)25fps/960P/ (1280×960)/720P(1280×720)25fps |
| PTZ | Supported |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 6TB, SATA Interface HDD*1 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK |
| Power Supply | 12V / 3A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-NVR-716128-4K
◆In face recognition mode, support the classification of face recognition black and white lists and trigger various linkage methods ◆Support to search for pictures and video files by face search ◆Support live capture, batch import and add face database, preview capture interface to add face database, add historical captured face database from intelligent retrieval, and export face database ◆Black and white list classification, support the linkage alarm of face black and white list classification
| Main Processor | Hi3536 |
| operating system | Embedded Linux |
| bandwidth | 640M |
| Video format | H.265+/H.265 /H.264 |
| Clarity | 4K / 5MP / 3MP / 1080P / 720P / D1 |
| Video mode | Timing recording and alarm recording, timing recording, alarm recording, stop recording, motion detection recording , network disconnection supplement recording (requires front-end support) |
| Audio input and output | 1 channel RCA audio input, 1 channel RCA audio output, HDMI audio |
| Alarm | 4 channels alarm input 4 channels alarm output |
| USB | 3 USB (2 USB2.0, 1 USB3.0) |
| Backup mode | U disk, network backup |
| HDD Capacity | ≤50W(without HDD ) |
| Network Interface | 2*RJ45 10M/100M/1000M adaptive | Power Supply | ATX110-220V 300W 50-60Hz |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-NVR-71664-4K
◆In face recognition mode, support the classification of face recognition black and white lists and trigger various linkage methods ◆Support to search for pictures and video files by face search ◆Support live capture, batch import and add face database, preview capture interface to add face database, add historical captured face database from intelligent retrieval, and export face database ◆Black and white list classification, support the linkage alarm of face black and white list classification
| Main chip | Hi3536 |
| operating system | Embedded Linux |
| Bandwidth | 640M |
| Video format | H.265+/H.265 /H.264 |
| Clarity | 4K / 5MP / 3MP / 1080P / 720P / D1 |
| Smart function | Human form detection, target counting, electronic fence, retrograde detection, off-post detection, face detection (requires front-end camera support) |
| Video mode | Timing recording and alarm recording, timing recording, alarm recording, stop recording, motion detection recording , network disconnection supplement recording (requires front-end support) |
| Replay ability | Support 1*4K/ 4*4K/9*3MP/16*1080P video synchronization playback |
| PlayBack | Regular playback, instant playback, event playback, external file playback |
| Backup mode | U disk, network backup |
| Face recognition | 16- way front-end comparison |
| Video input | 64CH digital (4000X3000) + 64CH preview + 16CH playback + 16-channel front-end face matching machine 36CH digital (4000X3000) + 36CH preview + 16CH playback 64CH digital (4000X3000) + 64CH preview + 16CH playback Support importing 5000 face libraries |
| Video output | 1 HDMI, 1 VGA |
| Audio input and output | 1 channel RCA audio input, 1 channel RCA audio output, HDMI audio |
| Alarm input and output | 4 channels alarm input 4 channels alarm output |
| hard disk | 16 SATA, maximum support 8TB |
| Network port | 2*RJ45 10M/100M/1000M adaptive |
| Internet function | DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P |
| Phone monitoring | iPhone, Android |
| USB | 3 USB (2 USB2.0, 1 USB3.0) | power supply | ATX110-220V 300W 50-60Hz |
| size | Equipment: 485mm×545mm×135mm, Packing: 670mmX571mmX226mm | weight | Net weight.: 14Kg; Gross weight: 15Kg |
| Packing specification | 1 set/carton. 685mmX586mmX251mm; weight: 16 kg |
SRK-NVR-71664-4K
◆In face recognition mode, support the classification of face recognition black and white lists and trigger various linkage methods ◆Support to search for pictures and video files by face search ◆Support live capture, batch import and add face database, preview capture interface to add face database, add historical captured face database from intelligent retrieval, and export face database ◆Black and white list classification, support the linkage alarm of face black and white list classification
| Main chip | Hi3536 |
| operating system | Embedded Linux |
| Bandwidth | 640M |
| Video format | H.265+/H.265 /H.264 |
| Clarity | 4K / 5MP / 3MP / 1080P / 720P / D1 |
| Smart function | Human form detection, target counting, electronic fence, retrograde detection, off-post detection, face detection (requires front-end camera support) |
| Video mode | Timing recording and alarm recording, timing recording, alarm recording, stop recording, motion detection recording , network disconnection supplement recording (requires front-end support) |
| Replay ability | Support 1*4K/ 4*4K/9*3MP/16*1080P video synchronization playback |
| PlayBack | Regular playback, instant playback, event playback, external file playback |
| Backup mode | U disk, network backup |
| Face recognition | 16- way front-end comparison |
| Video input | 64CH digital (4000X3000) + 64CH preview + 16CH playback + 16-channel front-end face matching machine 36CH digital (4000X3000) + 36CH preview + 16CH playback 64CH digital (4000X3000) + 64CH preview + 16CH playback Support importing 5000 face libraries |
| Video output | 1 HDMI, 1 VGA |
| Audio input and output | 1 channel RCA audio input, 1 channel RCA audio output, HDMI audio |
| Alarm input and output | 4 channels alarm input 4 channels alarm output |
| hard disk | 16 SATA, maximum support 8TB |
| Network port | 2*RJ45 10M/100M/1000M adaptive |
| Internet function | DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P |
| Phone monitoring | iPhone, Android |
| USB | 3 USB (2 USB2.0, 1 USB3.0) | power supply | ATX110-220V 300W 50-60Hz |
| size | Equipment: 485mm×545mm×135mm, Packing: 670mmX571mmX226mm | weight | Net weight.: 14Kg; Gross weight: 15Kg |
| Packing specification | 1 set/carton. 685mmX586mmX251mm; weight: 16 kg |
SRK-NVR-7232
Support 1080 recording Encoding Two high-speed USB2.0 interfaces Upto 6TB SATA Interface HDD*2 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support ONVIF Protocol H.265+ Supported
| Main Processor | HISILICON |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Control Mode | USB mouse, Keyboard, Network |
| Performance | 32CH@5MP |
| VGA / HDMI | VGA / HDMI : 1080(P) |
| Video | 32CH Resolution |
| Audio | 32CH Network Audio Input |
| Alarm | No |
| PlayBack | 4CH Playback |
| Digital Zoom | Yes |
| Protocol | Support ONVIF Protocol |
| Recording Resolution | 4K/5M/4M/1080P | PTZ | Supported |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 6TB, SATA Interface HDD*2 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK |
| Power Supply | 12V / 5A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-NVR-7432
Support 5MP recording Encoding Two high-speed USB2.0 interfaces Upto 6TB SATA Interface HDD*4 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support ONVIF Protocol H.265+ Supported
| Main Processor | H264/H265/H265+ |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Control Mode | USB mouse, Keyboard, Network |
| Performance | 32CH@5MP |
| VGA / HDMI | VGA / HDMI : 1080(P) |
| Video | 32CH Resolution |
| Audio | 32CH Network Audio Input |
| Alarm | No |
| PlayBack | 4CH Playback |
| Digital Zoom | Yes |
| Protocol | Support ONVIF Protocol |
| Recording Resolution | 4K/5M/4M/1080P | PTZ | Supported |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 6TB, SATA Interface HDD*4 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK |
| Power Supply | 12V / 6A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-NVR-7864
Support 1080P recording Encoding Two high-speed USB2.0 interfaces Upto 8TB SATA Interface HDD*8 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support ONVIF Protocol H.265 Supported
| Main Processor | HISILICON |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Control Mode | USB mouse, Keyboard, Network |
| Performance | 64CH@1080(P) |
| VGA / HDMI | VGA / HDMI : 1080(P) |
| Video | 64CH Resolution |
| Audio | 64CH Network Audio Input |
| Alarm | No |
| PlayBack | 4CH Playback |
| Digital Zoom | Yes |
| Protocol | Support ONVIF Protocol |
| Recording Resolution | 4K/5M/4M/1080P | PTZ | Supported |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 6TB, SATA Interface HDD*8 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK |
| Power Supply | 12V / 6A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-NVR-7964-5M
Support 4K/5MP recording Encoding Two high-speed USB3.0 interfaces Upto 10TB SATA Interface HDD*9 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support ONVIF Protocol H.265+ Supported
| Main chip | Hi3536 |
| operating system | Embedded Linux |
| Bandwidth | 512M |
| Video format | H.265+/H.265 /H.264 |
| Clarity | 4K / 5MP / 3MP / 1080P / 720P / D1 |
| Smart function | Human form detection, target counting, electronic fence, retrograde detection, off-post detection, face detection (requires front-end camera support) |
| Video mode | Timing recording and alarm recording, timing recording, alarm recording, stop recording, motion detection recording , network disconnection supplement recording (requires front-end support) |
| Replay ability | Support 1*4K/ 4*4K/9*3MP/16*1080P video synchronization playback |
| PlayBack | Regular playback, instant playback, event playback, external file playback |
| Backup mode | U disk, network backup |
| Face recognition | 16- way front-end comparison |
| Video input | 64CH digital (4000X3000) + 64CH preview + 16CH playback + 16-channel front-end face matching machine 36CH digital (4000X3000) + 36CH preview + 16CH playback 64CH digital (4000X3000) + 64CH preview + 16CH playback Support importing 5000 face libraries |
| Video output | 1 HDMI, 1 VGA |
| Audio input and output | 1 channel RCA audio input, 1 channel RCA audio output, HDMI audio |
| Alarm input and output | 4 channels alarm input 4 channels alarm output |
| hard disk | 16 SATA, maximum support 8TB |
| Network port | 2*RJ45 10M/100M/1000M adaptive |
| Internet function | DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P |
| Phone monitoring | iPhone, Android |
| USB | 3 USB (2 USB2.0, 1 USB3.0) | power supply | AC100-240V 200W |
| size | Equipment: 440mm×430mm×90mm, Packing: 539mmX530mmX225mm | weight | Net weight.: 7.4Kg; Gross weight: 9.8Kg |
| Packing specification | 2 sets/carton. 555mm×555mm×475mm; weight: 21 kg |
