SRK-HD-DVR
SRK-AHD-10821632
Support 1080 recording Encoding Two high-speed USB2.0 interfaces Upto 8TB SATA Interface HDD*2 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support LINUX Operating System
| Main Processor | H.264 |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Operating system | Embaded LINUX Operating System |
| Performance | 32CH AHD 1080 Realtime |
| VGA / HDMI | VGA Support : 1080P/HDMI Support : 1080P |
| Video | 32CH BNC input, 1 CH VGA, 1CH HDMI(1080) output |
| Alarm | No |
| PlayBack | 8CH at same time |
| Digital Zoom | Yes |
| Network Playback | Yes |
| PTZ | 1*RS485 Support pelco-D,pelco-P Protocol |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 8TB, SATA Interface HDD*2 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK, Network |
| Dimesion | 440*380*70mm |
| Power Supply | 12V / 6A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-AHD-16012
Support 1080 recording Encoding Two high-speed USB2.0 interfaces Upto 8TB SATA Interface HDD*1 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support LINUX Operating System
| Main Processor | H.264+ |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Operating system | Embaded LINUX Operating System |
| Performance | 32CH AHD 1080 Realtime |
| VGA / HDMI | VGA Support : 1080P/HDMI Support : 1080P |
| Video | 32CH BNC input, 1 CH VGA, 1CH HDMI(1080) output |
| Alarm | No |
| PlayBack | 8CH at same time |
| Digital Zoom | Yes |
| Network Playback | Yes |
| PTZ | 1*RS485 Support pelco-D,pelco-P Protocol |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 8TB, SATA Interface HDD*2 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK, Network |
| Dimesion | 440*380*70mm |
| Power Supply | 12V / 6A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-AHD-160216
Support 1080 recording Encoding Two high-speed USB2.0 interfaces Upto 8TB SATA Interface HDD*1 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support LINUX Operating System
| Main Processor | H.264+ |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Operating system | Embaded LINUX Operating System |
| Performance | 16CH AHD 1080 Realtime |
| VGA / HDMI | VGA Support : 1080P/HDMI Support : 1080P |
| Video | 16CH BNC input, 1 CH VGA, 1CH HDMI(1080P) output |
| Audio | 16CH RCA input, 1CH RCA ouput |
| Alarm | No |
| PlayBack | 4CH at same time |
| Digital Zoom | Yes |
| Network Playback | Yes |
| PTZ | 1*RS485 Support pelco-D,pelco-P Protocol |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 8TB, SATA Interface HDD*2 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK, Network |
| Dimesion | 335*250*50mm |
| Power Supply | 12V / 4A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-AHD-40104
Support 1080 recording Encoding Two high-speed USB2.0 interfaces Upto 8TB SATA Interface HDD*1 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support LINUX Operating System
| Main Processor | H.264+ |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Operating system | Embaded LINUX Operating System |
| Performance | 4CH AHD 1080 Realtime |
| VGA / HDMI | VGA Support : 1080P/HDMI Support : 1080P |
| Video | 4CH BNC input, 1 CH VGA, 1CH HDMI(1080P) output |
| Audio | 4CH RCA input, 1CH RCA ouput |
| Alarm | No |
| PlayBack | 4CH at same time |
| Digital Zoom | Yes |
| Network Playback | Yes |
| PTZ | 1*RS485 Support pelco-D,pelco-P Protocol |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 8TB, SATA Interface HDD*2 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK, Network |
| Dimesion | 250*230*45mm |
| Power Supply | 12V / 2A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
SRK-AHD-80104
Support 1080 recording Encoding Two high-speed USB2.0 interfaces Upto 8TB SATA Interface HDD*1 Backup, Mobile Monitoring, PTZ Control Support, Android, iPhone, Mac Support LINUX Operating System
| Main Processor | H.264+ |
| Pentaplex | Live recording, Playback, Backup Remote access, PTZ control, Mobile monitoring |
| Operating system | Embaded LINUX Operating System |
| Performance | 8CH AHD 1080 Realtime |
| VGA / HDMI | VGA Support : 1080P/HDMI Support : 1080P |
| Video | 8CH BNC input, 1 CH VGA, 1CH HDMI(1080P) output |
| Audio | 4CH RCA input, 1CH RCA ouput |
| Alarm | No |
| PlayBack | 4CH at same time |
| Digital Zoom | Yes |
| Network Playback | Yes |
| PTZ | 1*RS485 Support pelco-D,pelco-P Protocol |
| USB | 2 * USB2.0 |
| Mobile Phone | Support iPhone, Mac, and Android Mobile Phone |
| HDD Capacity | Up to 8TB, SATA Interface HDD*1 |
| Network Interface | 1*RJ45,100Mbps Ethernet |
| Upgrade / Backup | USB DISK, Network |
| Dimesion | 250*230*45mm |
| Power Supply | 12V / 3A |
| Working Environment | -10°~+55 °/10~90%RH/86~106Kpa |
